ADHCRETE ADHCOAT WATERGUARD

Package: 1 Ltr, 5 Ltr & 20 Ltr

Product Description

This product is specially formulated superior quality Waterproofing admixture to be mixed with 2 parts of Portland cement to form brush applicable slurry mortar which works as an excellent waterproofing agent. ADHCOAT WATERGUARD work as excellent waterproofing additive and bonding agent

Application Area

After proper cleaning of surface take 1 part of ADHCOAT WATERGUARD and 2 parts of Portland cement. Shake well the liquid component to a homogenous milky colour, before mixing transfer entire quantity of liquid component into a suitable clean mixing vessel, gradually start addition of powder component under constant mixing with a stirrer using a pneumatic or electric power tool (1 kw) at slow speed at 250-300 rpm for 3- 5 minutes to a homogeneous & uniform free flowing slurry. Apply mixed component by brush or roller on substrate.

For excellent result apply two coats. After application of first coat wait 3-4 hours for cure then apply second coat. Each coat thickness should not exceeds 1.5 mm and 1 mm is recommended. Allow 24 hours curing of final coat

Shelf Life & Storage

Shelf life is 12 months from the date of manufacturing if stored in factory sealed container. Store under cover, away from direct sunlight and protect from extreme temperature. In hot temperature conditions, it must be stored in a temperature-controlled environment i.e. less than 300 c.

Coverage

Approximately 9 to 10sft for kg in 1.5mm thickness. Will vary depends on job site condition

Installation Instructions

Cleaning equipment

While material is fresh clean the tools with water.

Maintenance

Properly installed material not required specific maintenance.

Warranty

ADHCRETE CONSTRUCTION TECHNOLOGY INDIA PVT LTD warrants to the original purchaser of this product that the product shall be free from defects and will not breakdown under normal usage for a period of one year from the date of manufacturing. Our sole liability under this warranty shall be limited to the replacement of purchased product if proved defective under normal handling as stated in TDS. This warranty will not extend to any other company product or items which were handled along with our product. This warranty or any other legal issues or claims subject to kundapura jurisdiction only.
Adhcrete Construction Technology India Pvt Ltd
Reg office –Sumukha Complex Uppunda-576232
Factory-Yaderi, Kalthodu village ,Kundapura-576219 Ph-08254-256760,
Website-www.adhcrete.com email-customercare@adhcrete.com

ADHCRETE ADHCOAT PAINT AND BOND

Package: 5.75 kg, 11.5kg & 46kg

Product Description

Paint and bond is a two component cementitious & acrylic flexible waterproofing & protective coating composed of best quality Portland cement, properly selected & graded aggregates, additives & acrylic emulsion polymer as a binder, specially designed for use on roofs, water tanks, and water retaining structure, as well as in bathrooms, showers, and kitchens, as on under tile protective membranes and a wide variety of extreme service class structures because on curing it forms an excellent elastomeric, waterproof & protective layer over the substrate.
The product is specially formulated superior quality latex admixture to be mixed with filler powder to form brush applicable slurry mortar which works as an excellent waterproofing agent.

APPLICATION

Pour the Part A to a clean bucket. Add Part B filler powder to a bucket and continuously stir by hand or slow speed mixer until get homogeneous slurry. Apply mixed component by brush or roller on substrate. For excellent result apply two coats. After application of first coat wait 3-4 hours for cure, then apply second coat. Each coat thickness should not exceed 1.5mm and 1 mm is recommended. Allow 14-16 hours curing of final coat before laying screed or tilling. Allow 24 hours curing of final coat.

APPLICATION AREA

1. Water tanks and swimming pools
2. Concrete& brick masonry
3. Cement plaster & cement mortar beds
4. Many dry wall boards

TECHNICAL INFORMATION

PROPERTIES	SPECIFICATION	RESULT
Nature	Two component	-
Colour	-	Grey
Elongation, %	-	<10%
Hydrostatic water pressure resistance, bar	ASTM D638	5 bar
Sp.gravity @ 25oc, g/cc	DIN 1048	1.85 to 2.0
Water Absorption,%	-	< 0.3
Pot Life at 35 C	ASTM C - 642	+/- 45 minutes

Shelf Life & Storage

Shelf life is 12 months from the date of manufacturing if stored in factory sealed container. Store under cover, away from direct sunlight and protect from extreme temperature. In hot temperature conditions, it must be stored in a temperature-controlled environment i.e. less than 30°C.

COVERAGE

Approximately 9 to 10sft for kg in 1.5mm thickness. Will vary depending on job site condition

Caution

• Store in cool and dry place
• High humidity and moisture will affect product property
• Protect finished work from traffic or damage by other trades for an extended period of time during cold weather conditions. At room temperature conditions 70°F (20°C), protect overnight.
• Keep out of reach of children.

Installation Instructions

Cleaning equipment

While material is fresh clean the tools with water.

Maintenance

Properly installed material does not require specific maintenance.

Warranty

ADHCRETE CONSTRUCTION TECHNOLOGY INDIA PVT LTD warrants to the original purchaser of this product that the product shall be free from defects and will not breakdown under normal usage for a period of one year from the date of manufacturing. Our sole liability under this warranty shall be limited to the replacement of purchased product if proved defective under normal handling as stated in TDS. This warranty will not extend to any other company product or items which were handled along with our product. This warranty or any other legal issues or claims subject to kundapura jurisdiction only.
Adhcrete construction technology india pvt ltd
Reg office –Sumukha Complex Uupunda-576232
Factory-Yaderi Kalthodu village ,Kundapura-576219
Ph-08254-256760,
Website-www.adhcrete.com email-customercare@adhcrete.com

WATER ADHCRETE ADHCOAT WATERPROOF

Package: 1, 5 and 20 ltrs

Product Description

ADHCOAT WATERPROOF is a carefully prepared, excellent quality, liquid waterproof membrane ready-to-use under thin and thick bed installations. It is a single component, self-curing liquid that forms a flexible, strong waterproofing membrane which provide bond directly to a wide variety of substrates.

AREAS TO USE

Interior and exterior, commercial, residential and industrial applications, swimming pools, Stalls, tub surrounds and other underwater applications; Food processing areas, bathrooms, kitchens and laundries and more.

APPLICATION

After proper cleaning of surface open the pail and stir properly. Apply mixed component by brush or roller on substrate. For excellent result apply two coats. After application of first coat wait 3-4 hours for cure then apply second coat. Each coat thickness should not exceeds 1 mm and 0.8 mm is recommended. Allow 14 to 16 hours curing of final coat before tiling and screeding. Flood test can be conducted after 24 hours of final coat.

COVERAGE

TROWEL SIZE	The coverage will be approximately 225 sq.ft. - 250 sq.ft. per 20 litres pail in 1.5 mm thickness, though the actual coverage will vary depending on conditions at the job site.
SHELF LIFE	Shelf life is 12 months from the date of manufacturing if stored in factory sealed container. Store in a shade under cover, away from direct sunlight and protected from extreme temperature. In hot temperature conditions, it must be stored in a temperature-controlled environment i.e. less than 30°C

ADH-CON (SBR) LATEX BONDING AGENT

Package: 1 ltr, 5 Ltr, 20 Ltrs & 220 kg barrel

Product Description

ADH-CON (SBR) is a water dispersion of an architectural grade acrylic latex specifically designed for modifying portland cement compositions. Mortar modified with ADH-CON (SBR) has improved physical strength, and superior adhesion to old concrete, masonry, brick, and many other surfaces. It is designed to mix with 2 parts of Portland cement and 1 part of silica sand at site before application. It works as an excellent bonding agent to old and new concrete and improves water resistence property and reduces shrinkage.

APPLICATION PROCEDURE

• General reconstruction work
• Repairs to precast structural members
• Bonding agent for old and new concrete
• Additive for repair mortar

APPLICATION

• 50 Kgs- cement
• 145 Kgs Zone II sand
• 10 KgsADH-CON SBR Latex
• 10 -13 liter Recommended water
• 10 mm - 30 mm recommended thickness

ADHCOAT DAMP PROOF

Package: 1 Ltr, 5 Ltr & 20 Ltrs

Product Description

ADHCrete ADHCOAT DAMP PROOF is a flexible, cold applied, odourless, rubber enriched bitumen emulsion for use both internally and externally. ADHCrete ADHCOAT DAMP PROOF provides a highly efficient sandwich damp-proof membrane for floors - ADHCrete ADHCOAT DAMP PROOF must be overlaid with a minimum 50mm flooring screed. It also acts as a waterproofer for walls when plastered or plaster boarded over. ADHCrete ADHCOAT DAMP PROOF must always be covered as it remains tacky.

APPLICATION FOR EXTERNAL WALL

Level uneven surfaces including brickwork, with cement mortar. Lightly dampen the surface with clean water. Apply 3 coats of ADHCOAT DAMP PROOF with a soft bristled brush, each at a coverage rate of 0.5 litres per m2 allowing each coat to dry before applying the next. Where possible ensure the ADHCOAT DAMP PROOF is keyed to the existing damp proof. ADHCOAT DAMP PROOF provides a waterproof membrane on bridge abutments, retaining walls, culverts, concrete or brick foundations and acts as a curing membrane when applied to green concrete.

Installation Instructions

ADHCRETE CORNER PLUS STRIP

Product Description

ADHCrete Corner Plus Strip is a ready-to-use, thin, strong yet flexible alkali-resistant mesh for embedment with waterproofing and crack-isolation membrane on residential and commercial floor joints & corners. ADHCrete Corner Plus Strip reinforces and improves the performance of Hydrobuild's waterproofing products when applied over cracks, coves and corners and around drains on residential and commercial applications. It has excellent compatibility with all cement or epoxy-based mortars.

APPLICATION

Clean the surface(corners) cleanly. Surface should be dry. Remove the sticker and apply / stick the strip from one edge to the other and press gently. Apply one coat of paint and bond or Water guard or Conlatex over the strip with regular brush or roller brush. Two coats for best result. Apply one coat ADHCrete waterproofing to corner. After drying, stick the strip to the corners.
